Guard Dog Low Profile 5 Channel Cable Protector - GD5X75-ST

The low profile 5 channel Guard Dog® cable protector ramp can accommodate five cables (or five groups of several smaller cables) each with a total outside diameter up to 0.75".

This is the standard ramp version; there is an alternative ADA compatible variant that is shown below in the related products. There are also one, two, and three channel variants available should you have smaller quantities of cables to accommodate.

Specification

Dimensions - A: length

36 in. (91.4 cm)

Dimensions - B: width

16.9 in. (43.0 cm)

Dimensions - C: height

1.25 in. (3.18 cm)

Dimensions - D: channel width

1.28 in. (3.25 cm)

Dimensions - E: channel height

.75 in. (1.9 cm)

Load Capacity - Per axle

48,000 lb./Axle (21,772 kg) (Max load tested at 70°F (21°C)

Load Capacity - Per tire

24,000 lb./Tire (10,886 kg) (Max load tested at 70°F (21°C)

Miscellaneous - Cable & hose diameter (max)

.75 in

Miscellaneous - Channels

5

Miscellaneous - Skus

GD5X75-ST-B/B, GD5X75-ST-O/B

Packaging - Weight

14.75 lb. (6.69 kg)
